Audio2000S AWM6031DU Handheld Wireless Microphone System
Audio2000S AWM6031DU Handheld Wireless Microphone System

Our Price: $109.95

Product Code: AWM6031DU

Audio2000S AWM6031DU Handheld Wireless Microphone System

AWM6031DU - UHF Single-Channel Diversity Wireless Microphone Systems

The Audio2000'S® AWM6031DU wireless system is a UHF single-channel diversity wireless microphone system. Similar to the other Audio2000'S® wireless systems, various transmitter options are provided to the AWM6031DU system users as follows:

Handheld Wireless Microphone System - AWM6031DU (AWR6031DU + AWX6030)


With the exceptional RF transmission and reception, the AWM6031DU system, with a transmission range of more than 150 feet, fully delivers all the reception and audio quality features that allow you to really enjoy the freedom of wireless without any of the problems.

Engineered For Dependable UHF Systems

As all the other Audio2000'S® wireless products, the AWM6031DU system has been engineered to be dependable UHF system with a wide audio frequency range, high S/N ratio, and outstanding performance equal to that of any professional wireless systems costing much more. This is achieved through strict component selection and high quality circuit design. A delicately designed silence circuit eliminates static noise when the transmitters are either turned off or out of transmission range. An auto mute circuit is incorporated in these systems to effectively eliminate the popping noise when the switch is turned on or off.

System Designed For Accessibility

The AWM6031DU system has been designed and manufactured to be dependable, problem free, versatile and easy to use. The AWM6031DU system is intended to be readily accessible to everyone with exceptional performance at a preferred and affordable price.


Musician; disc jockey (DJ); karaoke jockey (KJ); church; school; conference room; karaoke; home entertainment



* UHF Band Frequency
* One XLR Balanced Output and One 1/4" Unbalanced Audio Output
* RF Input with Built-in RF Preamplifier to Improve S/N Ratio, Sensitivity and DynamicRange
* Low Noise Mixer Circuitry for Reducing interference
* Squelch Control at the Rear Panel
* Diversity Receiver for Optimal Reception

* 12V-18V DC Power Supply


Carrier Frequency Range

UHF Band

Frequency Stability

± 0.005%

Receiving Sensitivity

-105 dBm

S/N Ratio



< 1%

Audio Output

¼” and XLR (0 – 300mV @ 600 Ohms)

Dimensions (W X H X D)

8.5” X 1.6” X 5.4” (215 X 40 X 138 mm)



* UHF Band Frequency
* High Sensitivity Cardioid Microphone Capsule
* Audio Level Adjustment Knob for the AWX6030M, AWX6030H, and AWX6030G
* Noise Reduction Mechanism for Eliminating Handling Noise and Switch Shock Noise

* Low Battery LED Indicator



Carrier Frequency Range

UHF Band

Frequency Stability

± 0.005%


Frequency Modulation (FM)

Modulation Depth


Output Power

30mW, Max

Spurious Emission

> 55 dB


9V Battery

Current Consumption

< 40 mA

Dimensions (W X H X D)

Handheld: 9.3” X 2.0” X 2.0” (235 X 50 X 50 mm)
Belt-Pack: 2.6” X 4.1” X 1.0” (65 X 105 X 25 mm)


Carrier Frequency Range

UHF Band

Frequency Stability

± 0.005%

Audio Frequency Response

80 – 15,000Hz

Image and Spurious Rejection

50dB Minimum

S/N Ratio

> 80dB

Max. SPL



< 1%

Service Area

150 ft (45 M)

Operation Temperature

14 °F – 122 °F (-10 °C – +50 °C)




  1. Set the antennas at an angle 45 from the floor and 90 away from each other to achieve the best RF reception.

  2. Connect the AWR6031DU receiver DC input to an AC power source via the supplied AC/DC adaptor.
    Connect the AWR6031DU receiver audio output to the microphone input of a mixer via the supplied audio cable or any other appropriate cable. (Note: There are two outputs: one unbalanced output and one balanced output.)

  3. Place one 9V battery into the battery housing of the AWX6030 microphone with the battery polarity oriented as indicated.

  4. Turn on the power of the AWR6031DU receiver. The Power On LED light will be turned on.

  5. On the AWX6030, the On/Off switch has three positions: “ON”, “MUTE” and “OFF”. When the On/Off switch is turned to the “MUTE” or directly to the “ON” position, the low battery LED indicator will blink once and then stay off. If the low battery LED indicator stays on, the 9V battery needs to be replaced. When the On/Off switch is set to the “MUTE” or “ON” position, the Antenna A or Antenna B LED light on the AWR6031DU receiver will be turned on. The AF LED light will be on whenever the AWX6030 receives any sound while the On/Off switch is set at the “ON” position.

  6. Adjust the volume control knob on the AWR6031DU receiver to have an optimal sound quality.



  1. The AWX6030 needs to be turned off before changing the 9V battery.
  2. Signal dropout or unexpected noise may be caused by a low battery or by an excessive distance between the transmitter and the receiver. If you encounter signal dropout or unexpected noise, please check the battery first. If battery is still fresh, try to readjust the antennas on the AWR6031DU receiver.
  3. Avoid placing the receiver in a corner to prevent any RF reception deterioration.
  4. Avoid placing the receiver antennas close to an obstruction or close to any metal surface.
  5. Try to place the receiver as far away from any digital equipment, including computers and some CD players, as possible.
  6. If more than one AWM6031DU wireless microphone systems are stacked together or placed in a rack, do not let the antennas touch each other or cross each other.
  7. Before the AWM6031DU is to be used in a new location, place the AWR6031DU receiver at the intended location and walk-through the area with the transmitter to locate any radio frequency blind spot, where a momentary loss of sound or short period of noise may occur whenever the transmitter is moved to this spot.
  8. Do not drop the transmitter on the floor or strike the transmitter with any object.
  9. Always turn off the transmitter and remove the battery if the transmitter is not to be used for a period of time to prevent the transmitter from being damaged by a leaking battery.




No sound.

Receiver is off.

Turn on receiver.

Transmitter power switch is off.

Turn on transmitter power switch.

No battery or bad battery in transmitter.

Insert or replace battery.

Wrong polarity or faulty battery contact

Correct polarity or battery contact.

Receiver audio cable is missing or defective.

Connect, repair or replace cable.

Short range or signal dropouts.

Low transmitter battery level.

Replace transmitter batteries.

Poor antenna reception.

Reposition antenna or receiver.

Faulty transmitter antenna.

Return transmitter to factory or authorized service station for service.

Too many obstacles between the receiver and transmitter.

Move the obstacles or move the receiver away from nearby metal objects.

Signal Interference.

Another wireless microphone operating on the same frequency

Use a wireless microphone with different operating frequency.

Placement too close to a digital signal processor or similar device (CD player, stage lighting, etc.).

1.Select another operating frequency

2.Move receiver to another location

External electromagnetic field source

1.Select another operating frequency.

2.Remove source of interference


Low transmitter battery level

Replace transmitter batteries.

AF Level control on the transmitter set too high, overloading the receiver circuit.

Turn down the AF Level control on the transmitter.

Volume control on the receiver set too high, overloading the subsequent sound device input.

Turn down the volume control on the receiver.

Momentary loss of sound when transmitter is moved around the performing area.

Radio frequency (RF) blind spots.

Reposition the receiver. If the momentary loss of sound problem cannot be removed, walk through the performing area and mark “Blind” spots. Avoid these “Blind” spots during performance.

Low sound level.

Faulty cable connection.

Check cable connection between the receiver and the subsequent sound device.

Receiver volume control set too low.

Turn up receiver volume control.

Sound levels between two microphones are different.

The receiver volume control and/or the microphone AF Level control need to be adjusted.

1.Adjust the transmitter gain control as necessary.

2.Adjust the receiver volume control as necessary.
